I/O Subsystem
R
112 Intel
®
815 Chipset Platform Design Guide
Figure 56. IDE Minimum/Maximum Routing and Cable Lengths
10-18 in.
4-6 in.5-12 in.
8 in. max.
ICH
IDE
connector
Traces
IDE_routing_cable_len
Figure 57. Ultra ATA/66 Cable
ATA66_cable
IDE connector
Black wires: ground
Grey wires: signals
