System Bus Design Guidelines
R
52 Intel
®
815 Chipset Platform Design Guide
5.4 PGA370 Socket Definition Details
The following table compares the pin names and functions of the Intel processors supported in the
Intel 815 chipset platform for use with the universal socket 370.
Table 12. Processor Pin Definition Comparison
Pin # Pin Name
Intel
®
Celeron™
Processor
(CPUID=068xh)
Pin Name
Intel
®
Pentium
®
III Processor
(CPUID=068xh)
Pin Name
Future 0.13
Micron
Socket 370
Processors
Function
AA33 Reserved VTT VTT • AGTL/AGTL+ termination
voltage
AA35 Reserved VTT VTT • AGTL/AGTL+ termination
voltage
AB36 VCC
CMOS
VCC
CMOS
VTT • CMOS voltage level for Intel
®
Pentium
®
III processor
(CPUID=068xh) and Intel
®
Celeron™ processor
(CPUID=068xh).
• AGTL termination voltage for
future 0.13 micron socket 370
processors.
AD36 VCC1.5 VCC1.5 VTT • VCC1.5 for Pentium III
processor (CPUID=068xh)
and Celeron processor
(CPUID=068xh).
• VTT for future 0.13 micron
socket 370 processors.
AF36 VSS VSS NC • Ground for Pentium III
processor (CPUID=068xh)
and Celeron processor
(CPUID=068xh).
• No connect for future 0.13
micron socket 370 processors.
AG1
1
VSS VSS VTT • Ground for Pentium III
processor (CPUID=068xh)
and Celeron processor
(CPUID=068xh).
• VTT for future 0.13 micron
socket 370 processors
AH4 Reserved RESET# RESET# • Processor reset for the
Pentium III processor (068xh)
and Future 0.13 micron socket
370 processors
AH20 Reserved VTT VTT • AGTL/AGTL+ termination
voltage
