13.3.2 Designs That Do Not Use the AGP Port
Any external graphics implementation not using the AGP port should terminate the GMCH AGP
control and strobe signals in the following way:
Table 34. Recommendations For Unused AGP Port
Signal Pull-up / Pull-Down
FRAME# Pull-up to +VDDQ
TRDY# Pull-up to +VDDQ
IRDY# Pull-up to +VDDQ
DEVSEL# Pull-up to +VDDQ
STOP# Pull-up to +VDDQ
SERR# Pull-up to +VDDQ
PERR# Pull-up to +VDDQ
RBF# Pull-up to +VDDQ
WBF# Pull-up to +VDDQ
INTA# Pull-up to +VDDQ
INTB# Pull-up to +VDDQ
PIPE# Pull-up to +VDDQ
REQ# Pull-up to +VDDQ
GNT# Pull-up to +VDDQ
GPAR Pull-down to Ground using a 100 kΩ
resistor
AD_STB[1:0] Pull-up to +VDDQ
SB_STB Pull-up to +VDDQ
AD_STB[1:0]# Pull-down to Ground
SB_STB# Pull-down to Ground
ST[2:0] Pull-up to +VDDQ
