Intel 815 - Page 213

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
INTEL(R) 82815 CHIPSET CUSTOMER REFERENCE BOARD
THERMTRIP
40
1.0
3-26-01
40
Platform Apps Engineering
1900 Prairie City Road
Folsom, CA 95630
REV.
R
Last Revision Date:
Sheet:
of
Title:
int
e
l
THERMTRIP#4
PWRBTN# 13,34
V1_8SB VCC1_8 V3SB
R352 1K
R350
1K
R349
1K
R353
1.6K
Q30
NPN
Q31
NPN
R351
22K
