Major Error Code Error Type Description
• A device cleaning failure
• An HPS configuration failure
Contact your local Field Applications Engineer (FAE). Alternatively, submit a Service Request on the
My Intel support page to get the support on capturing the error log for further debug.
0xF006
HPS_WATCHDOG_TIMEOUT
HPS watchdog timeout failure. Ensure that your design resets the watchdog timer correctly.
0xF007
INTERNAL_UNKNOWN_ERROR
Indicates an internal device error due to an unknown task.
You can contact your local Field Applications Engineer (FAE). Alternatively, submit a Service
Request on the
My Intel support page to get the support on capturing the error log for further
debug.
Table 37. CONFIG_STATUS and RSU_STATUS Minor Error Code Descriptions
Minor Error Code Error Type Description
0xD001
RSU_CMF_AUTH_ERR
Authentication failure for the firmware.
0xD002
RSU_USER_AUTH_ERR
Authentication failure for the design.
0xD003
RSU_CMF_DESC_SHA_MISMATCH
The SHA does not match for the firmware descriptor.
0xD004
RSU_POINTERS_NOT_FOUND_ERR
Unable to read data from boot ROM on first boot after the device exits power-on reset (POR).
0xD005
RSU_QSPI_REQ_CHANGE
Unable to configure the quad SPI flash during RSU initialization.
0xD006
RSU_FACTORY_IMAGE_FAILED
Failed to load any image, including the factory image.
0xD007
RSU_CMF_TYPE_ERR
The firmware version does not match the version that was previously loaded.
4.3.2. Error Code Responses
Table 38. Error Codes
Value (Hex) Error Code Response Description
0
OK
Indicates that the command completed successfully.
A command may erroneously return the OK status if a command, such as QSPI_READ is partially
successful.
1
INVALID_COMMAND
Indicates that the command is incorrectly formatted.
continued...
4. Remote System Update (RSU)
UG-20205 | 2019.10.09
Intel
®
Agilex
™
Configuration User Guide
Send Feedback
140
To Next Page
