Intel Agilex User Manual

Table 41. Sub-partition Table Layout
Offset Size (in bytes) Description
0x000
4 Magic number 0x57713427
0x004
4 Version number (0 for this document)
0x008
4 Number of entries
0x00C
20 Reserved
0x020
32 Sub-partition Descriptor 1
0x040
32 Sub-partition Descriptor 2
0xFE0
32 Sub-partition Descriptor 126
Each 32-byte sub-partition descriptor contains the following information:
Table 42. Sub-partition Descriptor Layout
Offset Size Description
0x00
16 Sub-partition name, including a null string terminator
0x10
8 Sub-partition start offset
0x18
4 Sub-partition length
0x1C
4 Sub-partition flags
4.4.2.3. Configuration Pointer Block Layout
The configuration pointer block contains a list of application images. The SDM tries the images in sequence until one of them
is successful or all fail. The structure contains the following information:
Table 43. Pointer Block Layout
Offset Size (in bytes) Description
0x00
4 Magic number 0x57789609
0x04
4 Size of pointer block header (0x18 for this document)
continued...
4. Remote System Update (RSU)
UG-20205 | 2019.10.09
Send Feedback
Intel
®
Agilex
™
Configuration User Guide
147
