Chapter 4: Operating instructions
TruVision DVR 12HD User Manual 21
Figure 3: TVR 12HD front panel
4-channel model:
16-channel model:
The controls on the front panel include:
Name Description
1
. USB 2.0 port Use the USB port to archive video, upgrade firmware, use a
USB mouse or connect a USB CD/DVD burner.
2
. Archive button Press once to enter quick archive mode. Press twice to start
archiving. If the USB stick has an LED, it will flash during
archiving.
3
. Display and Seq buttons Press Display to toggle through the various views (single and
multiviews). Press Seq to start/stop sequencing in live view
mode.
4
. Channel buttons Switch between different cameras in live view, PTZ control or
playback modes. Use the soft keyboard to enter numerals 0 to
9.
