Chapter 4: Operating instructions
22 TruVision DVR 12HD User Manual
Name Description
5
. Live, Menu and Search
buttons
Live: Switch to live view mode.
Press and hold for five seconds to lock live view. No actions
can be carried out from the front panel during this time. Mouse
actions are still allowed. Live view remains locked until the
button is pressed again for five seconds.
Menu: Enter/exit the main menu.
Search: Enter the advanced search menu.
6
. Status LEDs HDD: A steady GREEN light indicates that the recorder is
accessing the HDD in read or write operation. A steady RED
light indicates HDD failure.
Network: A steady GREEN light indicates that the recorder is
currently connected to a network. No light indicates that the
recorder is not connected to any network.
Internal: A steady GREEN light indicates that the recorder is
currently recording video/audio. A steady RED light indicates
internal health failure.
Alarm: A steady RED light indicates that there is a sensor
Alarm In. A steady GREEN light indicates no alarm.
7
. Alarm button Use to manually acknowledge an alarm.
8
. Enter and arrows buttons
Use to select options in a menu and to control playback. Press
for Enter.
Live view mode: Press Enter to enter/exit PTZ mode. Press
the left/right arrow buttons to scroll between the cameras.
Menu mode: To enter the menu toolbar, keep pressing the left
arrow button until the first menu icon is selected. Then press
the left/right arrow buttons to select a menu icon.
To select a menu option in the submenu panel or setup menu,
press the arrow buttons left/right and up/down to position
cursor in the menu window. Press for Enter. See Figure 12 on
page 27.
Playback mode: Press the left/right arrow buttons to slow
down or speed up playback. Press the up/down arrow buttons
to jump forwards or backwards by 30 seconds. Press Enter to
stop/start playback.
PTZ mode: Press the arrow buttons to control the movement
of the PTZ dome camera.
9
. IR receiver Receiver for IR remote.
10
. Playback buttons
Reverse: Press to jump back to the oldest available video
and start the playback.
Pause: Press to pause playback.
Play: Press to start 24-hour playback of the currently
selected camera. If you are in multiview format, only the
camera shown in the top-left corner of the multiview is played
back.
