SECTION 4 " RT1700 Radio Terminal
4-4 VT220/ANSI Terminal Emulation Programmer’s Reference Guide
Display Annunciators
Annunciators show the radio terminal’s current status or
operation in progress. The following annunciators can ap-
pear in the radio terminal’s display. Refer to the radio ter-
minal’s user guide for detailed information about the an-
nunciators that can appear for various battery conditions.
The radio terminal is transmitting information to
base station.
Communications loss. No communication with the
host computer has occurred for at least 60 seconds.
The radio terminal may be out of radio range, the base
station may not have power, or communications from
the host computer to the base station may not be prop-
erly set up.
T
X
C
L
The radio terminal’s keyboard is in gold shift mode.
The key you press while the terminal is in this mode
sends the character or does the function printed in
gold on the overlay and to the upper right of the key.
"
Y
The radio terminal’s keyboard is in shift mode. The
letter key you press while the keyboard is in this mode
sends letters in uppercase.
The radio terminal’s keyboard is in black shift
mode. The key you press while the terminal is in this
mode does programmable function key operations, or
sends the character printed in black on the overlay
and to the upper left of the key.
A
The battery needs to be recharged. When this an-
nunciator appears, you will not be able to operate your
radio terminal until you place it on a charger.
+
--
