SECTION 4 " RT1700 Radio Terminal
4-20 VT220/ANSI Terminal Emulation Programmer’s Reference Guide
37-Key Keyboard
You can use the control keys on the 37-key keyboard only
when the keyboard is in SHIFT LOCK mode. To put the
keyboard into SHIFT LOCK mode, press [BLACK]+
[GOLD]. Then press the key sequences listed in Table 4-7.
Table 4-7
RT1700 Control Keys (37-Key Keyboard)
To Do Action Press
CTRL A -- CTRL L [GOLD]+[8]+[F1] -- [GOLD]+[8]+[F12]
CTRL M [GOLD]+[8]+[SP]
CTRL N
[GOLD]+[8]+[¬]
CTRL O -- CTRL Q [GOLD]+[8]+[7] -- [GOLD]+[8]+[9]
CTRL R -- CTRL T [GOLD]+[8]+[4] -- [GOLD]+[8]+[6]
CTRL U -- CTRL W [GOLD]+[8]+[1] -- [GOLD]+[8]+[3]
CTRL X [GOLD]+[8]+[KEYPAD]
CTRL Y [GOLD]+[8]+[0]
CTRL Z [GOLD]+[8]+[.]
Transmission Mode
Use the transmission mode (labeled “mode” on the overlay)
to put the radio terminal into line edit (block) mode or char-
acter mode. To alternate between modes, press the follow-
ing keys:
[GOLD]+[7] on the 37-key keyboard
[BLACK]+[Y] on the 57-key keyboard
The modes are described on pages 8-55 and 8-56 in Section
8, “Programming.”
