INVT GD300L Series User Manual

Goodrive300-LIFT series inverter Communication protocol
-132-
Parameter
address
Inverter
address
Write
command
CRC
Data quantity
03 06 00 04 27 10 D3 D5
Note: The spaces in the above command are for illustration. No space can be added in the actual
application unless the upper monitor can remove spaces.
10.4.8.3 Example of continuous writing command10H
Example 1: Make the inverter whose address is 01H run forward at 10Hz. Refer to the instruction of
2000H and 0001. Set the address of "communication setting frequency" to 2001H and 10Hz
corresponds to 03E8H. See the table below.
Function
instruction
Address
definition
Data meaning instruction
R/W
property
Communication
control
command
2000H
0001H: Forward running
W/R
0002H: Reverse running
0003H: Forward jogging
0004H: Reverse jogging
0005H: Stop
0006H: Coast to stop (emergency stop)
0007H: Fault reset
0008H: Jogging stop
The address of
communication
setting
2001H
Communication setting frequency (0–Fmax, unit:
0.01Hz)
W/R
2002H
PID given, range (0–1000, 1000 corresponds
to100.0%)
Set P00.01 to 2.
The command sent to the inverter:
Parameter
address
Inverter
address
Continuous
write
command
Number of
bytes
Parameter
quantity
01 10 20 00 00 02 04
Froward
running
00 01
10 Hz
03 E8
CRC
3B 10
If the operation is successful, the response message is as below:
Parameter
address
Inverter
address
Continuous
write
command
CRC
Parameter
quantity
01 10 20 00 00 02 4A 08
Example 2: set the S-curve ACC start segment duration of 01H inverter as 2s and the S-curve ACC
end segment duration as 3s
