Goodrive300-LIFT series inverter Installation guide
-20-
4.3 Wiring
4.3.1 Connection to peripheral devices
Earth
Breaker or RCCB
Motor
DC reactor
Output
noise filter
Earth
Output AC
reactor
Inverter
Input
interference
filter
Brake resistor
MAgnetic
contactor (MC)
Input AC
reactor
Power supply
Figure 4-7 Connection to peripheral devices
