INVT GD300L Series User Manual

Goodrive300-LIFT series inverter Commissioning guidelines
-80-
Note:
• Set the motor parameters according to the motor name plate.
• Note the difference in synchronous and asynchronous motor parameter autotuning modes.
7.4.2 Adjusting maintenance running parameters
Maintenance running can be used to check whether the lift is running properly.
During maintenance, check whether the actual lift running direction is the same as the direction in the
command. If not, exchange any two cables of U, V, and W or set P00.06=1.
Note: For the synchronous motor, changing the motor cables requires autotuning the motor
parameter (pole angle) again. It is recommended to set P00.06 to change the lift running direction.
7.4.3 Adjusting the S curve for normal running
Before normal running, check whether the control logic is correct and wiring is correct. If they are
correct, adjust the S curve. For details, see the descriptions of P09.09–P09.16.
Function code
Name
Setting range
P01.01
Starting frequency of direct
startup
0.00–50.00 [0.00Hz]
P01.03
Starting frequency retention
time
0.0–50.0 [0.0s]
P01.12
Stop knee-point frequency
0.00–10.00 [1.00Hz]
P09.09
S-curve ACC start segment
duration
0.1–360.0 [2.0s]
P09.10
S-curve ACC end segment
duration
0.1–360.0 [2.0s]
P09.11
ACC time
0.1–360.0 [2.0s]
P09.12
S-curve DEC start segment
duration
0.1–360.0 [2.0s]
P09.13
S-curve DEC end segment
duration
0.1–360.0 [2.0s]
P09.14
DEC time
0.1–360.0 [2.0s]
P09.15
S-curve start segment duration
during stop
0.1–360.0 [2.0s]
P09.16
S-curve end segment duration
during stop
0.1–360.0 [2.0s]
P09.24
DEC time for creeping to stop
0.1–360.0 [2.0s]
