INVT GD300L Series User Manual

Goodrive300-LIFT series inverter Function parameters
-48-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
-10V–+10V.
Setting range of P05.17: 0.00V–P05.19
Setting range of P05.18: -300.0%–300.0%
Setting range of P05.19: P05.17–10.00V
Setting range of P05.20: -300.0%–300.0%
Setting range of P05.21: 0.000s–10.000s
Setting range of P05.22: 0.00V–P05.24
Setting range of P05.23: -300.0%–300.0%
Setting range of P05.24: P05.22–10.00V
Setting range of P05.25: -300.0%–300.0%
Setting range of P05.26: 0.000s–10.000s
P05.27
Lower limit
frequency of HDI
0.000 KHz – P05.29
0.000K
Hz
○
P05.28
Corresponding
setting of HDI
lower limit
frequency
-300.0%–300.0%
0.0%
○
P05.29
Upper limit
frequency of HDI
P05.27 –50.000kHz
50.000K
Hz
○
P05.30
Corresponding
setting of HDI
upper limit
frequency
-300.0%–300.0%
100.0%
○
P05.31
HDI frequency
input filter time
0.000s–10.000s
0.030s
○
P05.32
Analog signal
voltage
threshold for
motor thermal
protection
0.0 V–10.0 V
0.0 V
○
P05.33
Reserved
0–65535
0
○
P06 Group Output terminals
P06.00
HDO output
Function selection of the high-speed pulse
output terminals.
0: Open collector pole high speed pulse output.
The max.pulse frequency is 50.0kHz. See
P06.16–P06.20.
1: Open collector pole output. See P06.03.
0
◎
P06.01
Y1 output
0: No output
1: Lift in operation
2: Up operation
1
○
P06.02
Y2 output
0
○
