Goodrive300-LIFT series inverter Function parameters
-34-
6 Function parameters
6.1 What this chapter contains
This chapter lists and describes the function parameters.
6.2 Function parameters
The function parameters of GD300L series inverters special for lifts are divided into 30 groups
(P00–P29) by function, of which P18–P19 and P22–P28 are reserved. Each function group contains
certain function codes applying 3-level menus. For example, "P08.08" means the eighth function code
in the P8 group function. P29 group is factory reserved and inaccessible for users.
For the convenience of function codes setting, the function group number corresponds to the first
level menu, the function code corresponds to the second level menu and the function code
corresponds to the third level menu.
1. Below is the instruction of the function lists:
The first line "Function code": codes of function parameter group and parameters；
The second line "Name": full name of function parameters；
The third line "Detailed illustration of parameters": detailed illustration of the function parameters
The fourth line "Default value": the original factory values of the function parameter；
The fifth line "Modify": the modifying character of function codes (the parameters can be modified or
not and the modifying conditions), below is the instruction:
"○": means the set value of the parameter can be modified on stop and running state；
"◎": means the set value of the parameter cannot be modified on the running state；
"●": means the value of the parameter is the real detection value which cannot be modified.
(The inverter has limited the automatic inspection of the modifying character of the parameters to help
users avoid misadjustment.)
2. "Parameter radix" is decimal (DEC), if the parameter is expressed by hex, then the parameter is
separated from each other when editing. The setting range of certain bits are 0–F (Hex).
3. "The default value" means the function parameter will restore to the default value during default
parameters restoring, but the detected parameter or recorded value is not restored.
4. For a better parameter protection, the inverter provides password protection to the parameters.
After setting the password (set P07.00 to any non-zero number), the system will come into the state of
password verification firstly after the user press PRG/ESC to come into the function code editing state.
And then "0.0.0.0.0." will be displayed. Unless the user input right password, they cannot enter into
the system. For the factory setting parameter zone, it needs correct factory password (remind that the
users cannot modify the factory parameters by themselves, otherwise, if the parameter setting is
incorrect, damage to the inverter may occur). If the password protection is unlocked, the user can
modify the password freely and the inverter will work as the last setting one. When P07.00 is set to 0,
