INVT GD300L Series User Manual

Goodrive300-LIFT series inverter Function parameters
-70-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
The function code is used to set the Ethernet
communication speed.
P16.01
IP address 1
0–255
Set the IP addresses in Ethernet
communication.
IP address format:
P16.01.P16.02.P16.03.P16.04
IP address example: 192.168.0.1
192
◎
P16.02
IP address 2
168
◎
P16.03
IP address 3
28
◎
P16.04
IP address 4
11
◎
P16.05
Subnet mask 1
0–255
Set the subnet masks in Ethernet
communication.
Subnet mask format:
P16.05.P16.06.P16.07.P16.08
Subnet mask example: 255.255.255.0
255
◎
P16.06
Subnet mask 2
255
◎
P16.07
Subnet mask 3
255
◎
P16.08
Subnet mask 4
0
◎
P16.09
Gateway 1
0–255
Set the gateways in Ethernet communication.
192
◎
P16.10
Gateway 2
168
◎
P16.11
Gateway 3
28
◎
P16.12
Gateway 4
1
◎
P16.13
Reserved
0–65535
0
●
P16.14
Reserved
0–65535
0
●
P17 Group Monitoring function
P17.00
Set frequency
Display current set frequency of the inverter
Setting range: 0.00Hz–P00.04
0.00Hz
●
P17.01
Output
frequency
Display the current output frequency of the
inverter.
Setting range: 0.00Hz–P00.04
0.00Hz
●
P17.02
Ramp reference
frequency
Display current ramp given frequency of the
inverter.
Setting range: 0.00Hz–P00.04
0.00Hz
●
P17.03
Output voltage
Display current output voltage of the inverter.
Setting range: 0–1200V
0V
●
P17.04
Output current
Display current output current of the inverter.
Setting range: 0.0–5000.0A
0.0A
●
