INVT GD300L Series

Goodrive300-LIFT series inverter Product overview
-13-
Fixed hook for cover
Keypad panel
Control board
Control terminals
PG card expansion
Keypad bracket
Shield plate
Function card expansion
Main circuit terminals
Control cable port
Whole-unit
mounting hole
Fixed hook for cover
Keypad panel
Control board
Control terminals
PG card expansion
Keypad bracket
Shield plate
Function card expansion
Main circuit terminals
Control cable port
Whole-unit
mounting hole
Cover
Cover mounting hole
Vent hole
Figure 3-7 Components of inverters ≥18.5 kW
