INVT GD300L Series User Manual

Goodrive300-LIFT series inverter Function parameters
-54-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P07.28
Type of current
fault
0: No fault
1: Inverter unit U phase protection (OUt1)
2: Inverter unit V phase protection (OUt2)
3: Inverter unit W phase protection (OUt3)
4: ACC overcurrent (OC1)
5: DEC overcurrent (OC2)
6: Constant-speed overcurrent (OC3)
7: ACC overvoltage (OV1)
8: DEC overvoltage (OV2)
9: Constant-speed overvoltage (OV3)
10: Bus undervoltage (UV)
11: Motor overload (OL1)
12: Inverter overload (OL2)
13: Input side phase loss (SPI)
14: Output side phase loss (SPO)
15: Overheat of the rectifier module (OH1)
16:Overheat fault of the converter module (OH2)
17: External fault (EF)
18: 485 communication fault (CE)
19: Current detection fault (ItE)
20: Motor autotune fault (tE)
21: EEPROM operation fault (EEP)
22: PID response offline fault (PIDE)
23: Brake unit fault (bCE)
24: Running time arrival (END)
25: Electrical overload (OL3)
26: Panel communication fault (PCE)
27: Parameter uploading fault (UPE)
28: Parameter downloading fault (DNE)
29: PROFIBUS communication fault (E-DP)
30: Ethernet communication fault (E-NET)
31: CANopen communication fault (E-CAN)
32: Grounding short circuit fault 1 (ETH1)
33: Grounding short circuit fault 2 (ETH2)
34: Speed deviation fault (dEu)
35: Maladjustment (STo)
36: Undervoltage fault (LL)
37: Encoder offline fault (ENC1O)
38: Encoder reverse fault (ENC1D)
39: Encoder Z pulse offline fault (ENC1Z)
40: U disconnection (ENC1U)
●
P07.29
Type of last fault
●
P07.30
Type of last but
one fault
●
P07.31
Type of last but
two fault
●
P07.32
Type of last but
three fault
●
P07.33
Type of last but
four
●
P07.34
Type of last but
five fault
P07.35
Type of last but
six fault
P07.36
Type of last but
seven fault
