6700SR Refrigerated Sampler
124
Figure 40 Extended Programming: Hardware Screens
RUN "EXTENDED 1"
PROGRAM
VIEW REPORT
OTHER FUNCTIONS
MAINTENANCE
MANUAL FUNCTIONS
PROGRAMMING STYLE
HARDWARE
AT THE BEGINNING OF:
INITIAL PURGE
FORWARD PUMPING
DURING:
ENTIRE PUMP CYCLE
FORWARD PUMPING
BACKLIGHT ALWAYS OFF
TIMED BACKLIGHT
CONTINUOUS BACKLIGHT
EVENT MARK DURATION
3 SECONDS
WHILE PUMPING
PRE-SAMPLE PURGE:
RUN FLOW THRU PUMP
___SECONDS BEFORE
TAKING READINGS
(0-120)
____ COUNTS
(10-9999)
POST-SAMPLE PURGE:
DEPENDENT ON HEAD
FIXED COUNT
POST-SAMPLE PURGE:
____ COUNTS
(10-9999)
SET I/Ox:
NONE
<- I/O ENABLE
<- FR-TEMP
-> PGM RUNNING
-> PGM ENABLED
-> 'A' ENABLED
-> 'B' ENABLED
-> PROGRAM DONE
-> 'A' DONE
-> 'B' DONE
-> RUN ERROR
-> FLOW THRU
-> CONDITIONS
See Note B.
See Note A.
See Note A.
RAIN GAGE
0.01 inch TIP
0.1mm TIP
MASTER/SLAVE?
YES NO
ENABLE PROGRAM LOCK?
YES NO
CHANGE PASSWORD TO
YSI 600
OTHER YSI SONDE
NO YSI SONDE
_____
DO YOU HAVE A
RAIN GAGE CONNECTED?
YES NO
YES
NEW HARDWARE SETUP--
STORED DATA WILL
BE LOST! OK?
YES NO
If applicable
PARTITION MEMORY
WILL LAST __ DAYS
PLEASE WAIT!
YES
BOTTLE FULL DETECT?
YES NO
EVENT MARK SENT FOR
EVERY SAMPLE
COMPLETE SAMPLES
USE LIQUID DETECTOR?
YES NO
YES
REENTER NEW PASSWORD
_____
Notes
A. Software option. See Chapter 6.
B. <- denotes input signal.
-> denotes output signal.
NEW HARDWARE SETUP--
STORED DATA WILL
BE LOST! OK?
YES NO
See
Figure 42
,
Extended Programming:
YSI 600 Screens
, on page 126.
See
Figure 44
,
Analog Output and Dialout
Screens
, on page 128.
See
Figure 43
,
Extended Programming:
Optional YSI Screens
, on page 127.
See
Figure 35
,
Extended Programming:
Programmed Sampler Enable
, on page 119.
To Next Page
