Communication
USER MANUAL FPC 200 - 3/2017 103
8.3.3.5 Fault indications in monitor direction
INF
Semantics
<64>
Start/pick-up L
1
<65>
Start/pick-up L
2
<66>
Start/pick-up L
3
<67>
Start/pick-up N
X
<68>
General trip
<69>
Trip L
1
<70>
Trip L
2
<71>
Trip L
3
<72>
Trip I>> (back-up operation)
<73>
Fault location X in ohms
<74>
Fault forward/line
<75>
Fault reverse/busbar
<76>
Teleprotection signal transmitted
<77>
Teleprotection signal received
<78>
Zone 1
<79>
Zone 2
<80>
Zone 3
<81>
Zone 4
<82>
Zone 5
<83>
Zone 6
<84>
General start/pick-up
X
<85>
Breaker failure
<86>
Trip measuring system L
1
<87>
Trip measuring system L
2
<88>
Trip measuring system L
3
<89>
Trip measuring system E
X
<90>
Trip I>
X
<91>
Trip I>>
X
<92>
Trip IN>
X
<93>
Trip IN>>
