5.5 Connection
The FPC 200 connections are made to the removable connectors located on the rear side. Connectors are screw-lockable.
Direction from which wires are connected is defined by the type of the connector. Braided or single strand wires can be
used for the wiring. The braided wires must be correctly finished with insulated end-sleeve and executed with a suitable
tools. Soldering can endanger the integrity of wire connection and is not permitted.
Equipment shall be isolated or disconnected from hazardous live voltage before access to
potentially hazardous live parts is affected.
Recommended wire dimensions for individual device connections type are presented in Table 112.
Recommended
Power supply
1,5 mm
2
Current measurements
2,5 mm
2
Voltage measurements
1,5 mm
2
Digital inputs
0,75 mm
2
Digital outputs
1,5 mm
2
Analog outputs
1,5 mm
2
Grounding
4 mm
2
Table 112: Wire dimensions
Wire voltage rating: 500 V
