Mounting and commissioning
162 USER MANUAL FPC 200 - 3/2017
5.7 Commissioning
FPC 200 protection relay has undergone full factory control assuring proper work of its functions. Device calibrations was
done according to specified range. Once delivered the device is ready to operate without requiring any additional testing
of its functions that directly concerns it.
Traceable verification and systematic approach are provided with commissioning procedure. After following step-by-step
instructions with all tests passing requirements the device is ready for normal operation.
Only carry out the tests suited to the hardware configuration and the functions activated.
Handling conditions
During handling of the device the ESD standard should be observed. Individual internal modules shall not be withdrawn or
inserted while device is energized. In withdrawn condition some internal modules might be electrostatically endangered if
not handled according to ESD standard. Internal modules are not electrostatically endangered when inserted into the
case.
Testing equipment required
Based on device type current or voltage source is required.
5.7.2.1 Generators
Sinusoidal AC current generator
Sinusoidal AC voltage generator
DC voltage generator
5.7.2.2 Measuring instruments
Ammeter
Voltmeter
5.7.2.3 Documents
User manual FPC 200
5.7.2.4 Computer equipment
Windows XP/Vista/7/8/10
Processor: 1 GHz
RAM: 512 MB
Disk space:
o 600 MB (32-bit system)
o 1,5 GB (64-bit system)
Monitor with VGA resolution
MiQen software installed
Device overall check
Before setting any parameters the device has to pass initial test. The test checks that correct device is chosen and if
device starts up properly. Upon passing this test the device is ready for further commissioning.
5.7.3.1 Visual inspection
Device identification
Conformity of the device auxiliary power supply
5.7.3.2 Connections
Correct connection according to connection
scheme
Correctly grounded device
