Technical data
168 USER MANUAL FPC 200 - 3/2017
6.1 Type tests
Electromagnetic Compatibility
Standard
Level/Class
Value
Emission
Conducted Disturbance Emission
IEC 60255-26
CISPR 22
A
0,15 MHz to 30 MHz*
EN 55022
IEC 61000-6-4
A
Radiated emission (bellow 1 GHz)
IEC 60255-26
30 MHz to 1000 MHz*
CISPR 11
EN 55022
IEC 61000-6-4
A
A
Radiated emission (above 1 GHz)
IEC 60255-26
1 GHz to 6 GHz*
CISPR 22
EN 55022
IEC 61000-6-4
A
A
Immunity
Electrostatic Discharge
IEC 60255-26
15 kV air discharge*
IEC 61000-4-2
Level 4
8 kV direct discharge*
Radiated immunity
IEC 60255-26
10 V/m; 80 MHz to 2,7 GHz
IEC 61000-4-3
3
27 MHz to 500 MHz
ENV 50204 (GSM)
3
10 V/m; 2 W at 0.6 m
Fast transient / burst immunity
IEC 60225-26
4 kV
IEC 61000-4-4
4
4 kV
Surge immunity
IEC 60255-26
2 kV symmetrical (line to line)*
IEC 61000-4-5
3,4
4 kV unsymmetrical (line to earth)*
Conducted immunity
IEC 60255-26
0,15 MHz to 80 MHz; 10 V*
IEC 61000-4-6
3
Power frequency magnetic field immunity
IEC 60255-26
30 A/m continuous *
IEC 61000-4-8
4
Power frequency magnetic field immunity
IEC 60255-26
300 A/m; 1 s to 3 s*
IEC 61000-4-8
4
Pulse magnetic field immunity
IEC 61000-4-9
5
1000 A/m
Damped oscillatory magnetic field immunity
IEC 61000-4-10
4
30 A/m
Oscillatory transient immunity – Ring wave
IEC 61000-4-12
4
100 kHz
4 kV common mode
2 kV differential mode
Oscillatory transient immunity – Slow damped
oscillatory wave
IEC 61000-4-18
ANSI/IEEE Std
C37.90.1
3
100 kHz*
1 kV differential mode*
2,5 kV common mode*
Oscillatory transient immunity – Slow damped
oscillatory wave
IEC 60255-26
IEC 61000-4-18
3
1,0 MHz*
2,5 kV common mode*
ANSI/IEEE Std
C37.90.1
2,5 kV differential mode*
Voltage dips
IEC 60255-26
0 %*
IEC 61000-4-11
DC 100 ms
IEC 61000-4-29
AC 5 cycles (100 ms)
Voltage dips
IEC 60255-26
40 %*
IEC 61000-4-11
DC 200 ms
IEC 61000-4-29
AC 10 cycles (200 ms)
Voltage dips
IEC 60255-26
70 %*
IEC 61000-4-11
DC 500 ms
IEC 61000-4-29
AC 25 cycles (500 ms)
Voltage interruptions
IEC 60255-26
0 %*
IEC 61000-4-11
DC 5 s
IEC 61000-4-29
AC 250 cycles (5 s)
Ripple
IEC 60255-26
15 % of DC.; 100 Hz*
IEC 61000-4-17
