Technical data
USER MANUAL FPC 200 - 3/2017 169
Mechanical durability
Standard
Level/Class
Value
Energized
Seismic
IEC 60255-27
Class 1
IEC 60255-21-3
IEC 60068-2-6
Sinusoidal vibration response
IEC 60255-27
Class 1
10 Hz to 60 Hz: 0,075 mm*
IEC 60255-21-1
60 Hz to 150 Hz: 1 g*
IEC 60068-2-6
1 cycle in each axis*
Shock response
IEC 60255-27
Class 1
5 g; 11 ms*
IEC 60255-21-2
IEC 60068-2-27
De-energized
Sinusoidal vibration endurance
IEC 60255-27
Class 1
9 to 350 Hz; 2 G acceleration; 20
sweep cycles*
IEC 60255-21-1
IEC 60068-2-6
Shock withstand
IEC 60255-27
Class 1
15 g; 11 ms*
IEC 60255-21-2
IEC 60068-2-27
Bump
IEC 60255-27
Class 1
IEC 60255-21-2
IEC 60068-2-27
Environmental Tolerances
Standard
Level/Class
Value
Operation
Cold operation
IEC 60255-27
-25 °C; 16h*
IEC 60255-1
IEC 60068-2-1
Ad
Dry heat operation
IEC 60255-27
70 °C; 16 h*
IEC 60255-1
IEC 60068-2-1
Bd
Damp heat (static)
IEC 60255-27
55 °C; 93 % R.H.; 10 days*
IEC 60255-1
IEC 60068-2-78
Cyclic temperature with humidity (damp heat cyclic)
IEC 60255-27
IEC 60255-1
55 °C to 25 °C; 95 % R.H.; 12 h + 12 h; 6
cycles*
IEC 60068-2-30
Relative humidity
IEC 60068-2-30
Up to 95 % at 55 °C
Absolute humidity
IEC 60068-2-30
Up to 97 g/m
3
at 55 °C
Temperature gradient (change of temperature)
IEC 60068-2-14
5 cycles; -25 °C to 70 °C
Storage (must be stored in its original packing)
Exposure to Cold
IEC 60255-27
-25 °C; 16 h*
IEC 60255-1
IEC 60068-2-1
Dry heat storage
IEC 60255-27
70 °C; 16 h*
IEC 60255-1
IEC 60068-2-2
Safety
Standard
Level/Class
Value
Electrical
Insulation resistance
IEC 60255-27
> 100 MΩ at DC 500 V
Impulse voltage
IEC 60255-27
5 kV; 1,2 / 50 µs; 0,5 J
Power frequency dielectric withstand
IEC 60255-27
3,5 kV; 50 Hz; 1 min (PS, DI, DO, I, RS-485
AO)
4,35 kV; 50 Hz; 1 min (U)
Enclosure
Dust/water ingress
IEC 60255-27
IEC 60529
IP54 (front), IP40 (back)*
Insulation class
Class I
Table 115 Type tests of the device *same values for all stated standards
