Functionality
USER MANUAL FPC 200 - 3/2017 77
Setting parameters
Parameter
Range
Description
Control parameters
Sample rate
400 Hz
800 Hz
1600 Hz
3200 Hz
Data recording sample rate. The setting effects on duration of the record.
Duration
(depends on
sample rate setting)
5120 ms
2560 ms
1280 ms
640 ms
Record duration calculated based on selected sample rate. Duration is
informative and not user definable parameter.
Pretrigger
0 … 25 … 100 %
Time in percent of total duration of the record, that presents the fault
recorded before actual trigger.
Triggers
Pickup
Yes
No
Enabling trigger on appearance of any trip signal.
Trip
Yes
No
Enabling trigger on appearance of any pickup signal.
DO 1 … 8
Yes
No
Enabling trigger on signal dedicated to activate user defined DO
respectively.
DI 1 … 10
Yes
No
Enabling trigger on activated DI signal respectively.
Table 74 Disturbance recording function parameters.
