5.7.6.1 LED test
Test procedure is started by selecting Start LED test. There are several stages where every single LED as well as combined
functionality is tested. Single LED is tested by first lighting up for a short time and then blinking. Display provides
information needed to monitor the procedure.
Sequence is comprised of:
All LEDs turned on, display showing All LEDs are on
All LEDs turned off, display showing LEDs are off
Individual LED testing:
o Ready LED at first turned on and then flashing, display showing Testing Ready LED
o Alarm LED at first turned on and then flashing, display showing Testing Alarm LED
o LEDs 1 to 12 individually turned on and then flashing, display showing Testing LED number (01-12)
LEDs are turned consecutive from Ready to LED number 12 for three times. Display shows corresponding LED.
Upon completion the initial Test mode menu is displayed and only ready LED is turned on. Test is successful if device plays
the sequence as described above.
5.7.6.2 HMI test
Test procedure is started by selecting Start display test. Sequence is comprised of:
backlight turning off
backlight turning on
backlight turning off
backlight turning on
backlight gradually turning off while text Backlight off is shown
backlight gradually turning on while text Backlight on is shown
Upon completion the initial Test mode menu is displayed and only ready LED is turned on. Test is successful if device plays
the sequence as described above.
5.7.6.3 Test output relays
Test digital outputs enables user to control and triggers individual output relay. By selecting DO a confirmation windows is
displayed. When confirmed the selected output relay is triggered for a short period of time. In order to pass the test each
digital output should be tested.
In case of output being connected to
control equipment or even circuit breaker
during testing imminent danger is
presented.
Password level 2 is required.
Test is passed if each output can be triggered.
