Functionality
USER MANUAL FPC 200 - 3/2017 71
2.6.3.4 Predefined values
Constant
Value
Description
Max trip time
1 s
Maximum duration when trip signal can be present. Dynamic block is set if trip
signal duration exceeds Max trip time.
Block delay
1 s
Blocking time after dynamic blocking conditions occur. Standby conditions are
checked when Block delay time elapses.
Maximum close pulse
time
0,3 s
Maximum duration of Close command output pulse.
Table 66: Auto-reclosing function predefined values.
2.6.3.5 Counters
Name
Description
1
st
cycle
Consecutive number of active first cycles of the function.
2
nd
cycle
Consecutive number of active second cycles of the function.
3
rd
cycle
Consecutive number of active third cycles of the function.
Define trip
Consecutive number of
Table 67 Counters presented auto-reclosing function.
