Communication
86 USER MANUAL FPC 200 - 3/2017
Trip signals
121
R
Protection RUV [27R]
121.0
R
Protection PSUV 1 [27D - 1]
121.1
R
Protection PSUV 2 [27D - 2]
121.2
R
Protection OV 1 [59 - 1]
121.3
R
Protection OV 2 [59 - 2]
121.4
R
Protection NVD 1 [59NG - 1]
121.5
R
Protection NVD 2 [59NG - 2]
121.6
R
Reserved
121.7
R
Reserved
121.8
R
Protection OF 1 [81H - 1]
122.9
R
Protection OF 2 [81H - 2]
122.10
R
Protection UF 1 [81L - 1]
122.11
R
Protection UF 2 [81L - 2]
122.12
R
Reserved
122.13
R
Reserved
122.14
R
Protection TO [49T]
122.15
R
Trip signals
122
R
Protection MTO [49M]
122.0
R
Protection LR [48/51LR/14]
122.1
R
Protection SPH [66]
122.2
R
Protection EXT 1
122.3
R
Protection EXT 2
122.4
R
Thermostat 1
122.5
R
Thermostat 2
122.6
R
Buchholz 1
122.7
R
Buchholz 2
122.8
R
Protection ROCOF [81R]
122.9
R
Protection TMO 1 [38/49T - 1]
122.10
R
Protection TMO 2 [38/49T - 2]
122.11
R
Protection TMO 3 [38/49T - 3]
122.12
R
Protection TMO 4 [38/49T - 4]
122.13
R
Protection TMO 5 [38/49T - 5]
122.14
R
Protection TMO 6 [38/49T - 6]
122.15
R
Trip signals
123
R
Protection TMO 7 [38/49T - 7]
123.0
R
Protection TMO 8 [38/49T - 8]
123.1
R
Protection TMO 9 [38/49T - 9]
123.2
R
Protection TMO 10 [38/49T - 10]
123.4
R
Protection TMO 11 [38/49T - 11]
123.5
R
Protection TMO 12 [38/49T - 12]
123.6
R
Protection TMO 13 [38/49T - 13]
123.7
R
Protection TMO 14 [38/49T - 14]
123.8
R
Protection TMO 15 [38/49T - 15]
123.9
R
Protection TMO 16 [38/49T - 16]
123.10
R
Table 89 Modbus communication table.
