Communication
USER MANUAL FPC 200 - 3/2017 91
Counter status – Voltage protections
Word address (0x)
Access
Protection UV 1 [27 - 1]
10FD
R
Trip
10FD
R
Pickup
10FE
R
Pickup L
1
10FF
R
Pickup L
2
1100
R
Pickup L
3
1101
R
Protection UV 2 [27 - 2]
1102
R
Trip
1102
R
Pickup
1103
R
Pickup L
1
1104
R
Pickup L
2
1105
R
Pickup L
3
1106
R
Protection RUV [27R]
1107
R
Trip
1107
R
Pickup
1108
R
Protection PSUV 1 [27D - 1]
1109
R
Trip
1109
R
Pickup
110A
R
Protection PSUV 2 [27D - 2]
110B
R
Trip
110B
R
Pickup
110C
R
Protection OV 1 [59 - 1]
110D
R
Trip
110D
R
Pickup
110E
R
Pickup L
12
110F
R
Pickup L
23
1110
R
Pickup L
31
1111
R
Protection OV 2 [59 - 2]
1112
R
Trip
1112
R
Pickup
1113
R
Pickup L
12
1114
R
Pickup L
23
1115
R
Pickup L
31
1116
R
Protection NVD 1 [59NG - 1]
1117
R
Trip
1117
R
Pickup
1118
R
Protection NVD 1 [59NG - 2]
1119
R
Trip
1119
R
Pickup
111A
R
Reserved
111B
R
Reserved
111C
R
Reserved
111D
R
Reserved
111E
R
Table 94 Modbus communication table.
