1.2 Scope of supply
The scope of supply includes:
Table 1: Scope of supply
1x
item Servo Positioning Controller C 3-Series
Type Controller C 3-05 Controller C 3-10
item order number 0.0.668.65 0.0.668.66
Mating connectors for power, control, or shaft encoder connections are not part of the standard scope of supply. However,
they can be ordered as accessories.
Table 2: Connector set: POWER connector
1x
Connector set: POWER connector
This connector set includes the mating connectors for the following connections:
- Power supply [X9]
- Motor connection [X6]
Type
Controller C 3-05 Controller C 3-10
item order number
auf Anfrage erhältlich
Table 3: Connector set: DSUB connector
1x
Connector set: DSUB connector
This connector set includes the mating connectors for the following connections:
- I/O interface [X1]
- Angle encoder connection [X2A]
- Angle encoder connection [X2B]
- CAN fieldbus interface [X4]
- Incremental encoder input [X10]
- Incremental encoder output [X11]
Type
Controller C 3-05 Controller C 3-10
item order number
auf Anfrage erhältlich
Table 4: Connector set: shield connector
1x
Connector set: shield connector
This connector set includes two shield terminals (SK14)
Type
Controller C 3-05 Controller C 3-10
item order number 0.0.668.19
