ITEM C 3-Series User Manual

Technical data
Page 39
4.4 Motor connector [X6]
Table 13: Technical data: motor connector [X6]
Type
Controller C 3-05
Controller C 3-10
Specifications for operation with 3x 400 VAC [± 10%], 50 Hz
Nominal output power 3.0 kVA 6.0 kVA
Max. output power for 5 s 6.0 kVA 12.0 kVA
Nominal output current 5 A
RMS
10 A
RMS
Max. output current for 5 s 10 A
RMS
(15 A
RMS
for 2 s)
20 A
RMS
Max. output current for 0.5 s *) 20.0 A
RMS
(f
el
≥ 20 Hz)
40.0 A
RMS
(f
el
≥ 20 Hz)
Current derating from 12.5 kHz 5 kHz
Clock frequency 4 … 16 kHz (programmable via the software)
Holding brake 24 V Signal level depending on the switching state,
high-side/low-side switch / 2 A max.
Motor temperature sensor Normally closed contact, normally open contact, PTC, KTY
+ 3.3 V/5 mA
Power loss/efficiency (with regard to the
nominal power)**)
Typically 8% / 92%
*) In the case of lower electrical rotational frequencies (f
el
), shorter periods apply to the Controller C 3-05 and Controller C 3-10; see the
following tables.
**) "As a rating guideline".
