Page #69 background image
Mechanical installation
Page 69
7 Mechanical installation
7.1 Important notes
Only use the item Servo Positioning Controller C 3-Series as a built-in device for switch cabinets.
Vertical mounting position with supply lines [X9] on top.
Mount it to the control cabinet plate using the fastening tab.
Installation clearance:
Keep a minimum distance of 100 mm above and under the device with regard to other components in order to ensure
sufficient ventilation.
For optimal wiring of the motor cable and angle encoder cable under the device, an installation clearance of 150 mm is
recommended!
item Servo Positioning Controller C 3-Series may be installed directly next to one another on a heat-dissipating back plate,
provided that they are installed properly and used as intended. Please note that excessive heat may cause premature
ageing of and/or damage to the device. In case the item Servo Positioning Controller C 3-Series are subject to high
thermal stress, a mounting clearance of 75 mm is recommended!
The connections shown in the following illustrations apply to the item Servo Positioning Controller C 3-05 and
Controller C 3-10!
