Technical data
Page 38
4.3 Power supply [X9]
Table 10: Technical data: power data [X9]
Type
Controller C 3-05
Controller C 3-10
Supply voltage 3 x 230 ... 480 VAC [± 10%], 50 ... 60 Hz
Maximum mains current in continuous
operation
5 A
RMS
9 A
RMS
DC bus circuit voltage (in the case of a supply
voltage of 400 VAC)
560 ... 570 VDC
Alternative DC supply 60 ... 700 VDC
24 V supply 24 VDC [± 20%], (1 A)
*)
*)
plus the current consumption of a holding brake and I/Os (if included)
Table 11: Technical data: internal braking resistor [X9]
Type
Controller C 3-05
Controller C 3-10
Braking resistor 68 Ω
Peak power 8.5 kW
Continuous power 110 W
Response threshold 760 V
Overvoltage detection 800 V
Table 12: Technical data: external braking resistor [X9]
Type
Controller C 3-05
Controller C 3-10
Braking resistor ≥ 40 Ω
Continuous power ≤ 5000 W
Operating voltage ≥ 800 V
