ITEM C 3-Series - Table 16: Controller C 3-10: Rated Current Values for a Blocked or Slow-Running Motor

Technical data
Page 42
Table 16: Controller C 3-10: rated current values for a blocked or slow-running motor
(f
el
) ≤ 5 Hz and for an ambient temperature ≤ 40°C
Parameter
Values
Power output stage clock frequency (kHz) ≤ 5
Nominal current (A
RMS
) 10
Max. output current (A
RMS
) 20 30 40
Max. permissible time (s) 5 0.1 0.07
Power output stage clock frequency (kHz) 10
Nominal current (A
RMS
) 7
Max. output current (A
RMS
) 14 21 28
Max. permissible time (s) 5 0.1 0.06
Power output stage clock frequency (kHz) 16
Nominal current (A
RMS
) 3.45
Max. output current (A
RMS
) 6.9 10.35 13.8
Max. permissible time (s) 5 0.2 0.15
