Technical data
Page 47
Shaft encoders with HIPERFACE
®
made by Sick-Stegmann are supported in their single-turn and multi-turn variants. The
following encoder models can be connected:
 Single-turn SinCos encoders: SCS 60/70, SKS 36, SRS 50/60/64, SEK 37/52
 Multi-turn SinCos encoders: SCM 60/70, SKM 36, SRM 50/60/64, SEL 37/52
 Single-turn SinCos encoders for hollow shaft drives: SCS-Kit 101, SHS 170, SCK 25/35/40/45/50/53
 Multi-turn SinCos encoders for hollow shaft drives: SCM-Kit 101, SCL 25/35/40/45/50/53
In addition, the following Sick-Stegmann encoder systems can be connected and evaluated:
 Absolute, non-contact length measuring system L230 and TTK70 (HIPERFACE®)
 Digital incremental encoder CDD 50
SinCoder
®
encoders like SNS 50 or SNS 60 are no longer supported.
Heidenhain encoders:
Incremental and absolute encoders by Heidenhain can be evaluated. The following encoder models can be connected:
 Analogue incremental encoders: ROD 400, ERO 1200/1300/1400, ERN 100/400/1100/1300
 Single-turn absolute encoders (EnDat 2.1/2.2): ROC 400, ECI 1100/1300,
ECN 100/400/1100/1300
 Multi-turn absolute encoders (EnDat 2.1/2.2): ROQ 400, EQI 1100/1300, EQN 100/400/1100/1300
 Absolute length measuring system (EnDat 2.1/2.2): LC 100/400
Yaskawa:
Digital incremental encoders with index pulse [Σ (sigma 1), Yaskawa OEM protocol] made by Yaskawa are supported.
