Jacobsen HR 5111

45
> Change from previous revision
HR-5111
Item Part No. Qty. Description Serial Numbers/Notes
1
2720168 1 Lever, Throttle Control
2 326731 1 Knob, Throttle
3 162478 1 Ball Joint
4 339023 1 Cable, Throttle
5 443104 2 Nut, 1/4-28 Hex
6 366132 1 Plate, Throttle
7 360885 2 Disc, Friction
8 315966 1 Spring, Compression
9 319755 1 Washer
10 366134 1 Screw, 3/8-16 x 5” Special
11 444762 1 Locknut, 3/8-16 Center
12 400124 1 Screw, 1/4-20 x 2-1/2” Hex Head
13 446130 2 Lockwasher, 1/4 Heavy
14 443102 2 Nut, 1/4-20 Hex
8.1 Throttle
Serial No. 69116-5901 and Up
1
2
3
4
5
6
7
8
9
10
11
12
13
14
5
7
13
14
