MAINTENANCE & LUBRICATION CHARTS 6
GB-29
6.3 MAINTENANCE CHARTS ___________________________________________________
A - Add or Adjust C - Clean I - Inspect L- Lubricate R - Replace AR - As Required
* Indicates initial service for new machines.
** Or every two years whichever comes first.
*** Inspect visible hoses and tubes for leaks or oil marks.
**** Or when service indicator light comes on.
I
- Manual grease gun with NLGI Grade 2 (Service Class
LB).
II
- Engine Oil - See Section 4.5
III
- Use Textron Turf Care And Specialty Products hydraulic
fluid: Capacity: 5 gallons (19 Liters). Order Part No.
2500548 carton, containing two 2-1/2 gal. (9.5 liter)
bottles or Part No. 2500546 containing 5 gal. (19 liters),
pail.
IV
- Capacity: 3qt. (2.8 l) 50/50 water ethylene glycol mix.
V
- Heavy Duty 116-DOT-3
VI
- Capacity 2 Quarts 90 Weight gear lube
Recommended Service and Lubrication Intervals
Every
8-10
Hours
Every
25
Hours
Every
100
Hours
Every
250
Hours
Every
400
Hours
Every
500
Hours
Every
1000
Hours
Yearly See
Section
Lubricant
Type
Air Filter (Cab)
IR
Air Filter (Engine)
I R**** 4.6
Battery Charge
I4.9
Belts
I-A* I-A R 4., 3.2
Brake (Hydraulic)
I-A
V
Brake (Parking)
I-A A
Cooling System
I-C-A R 4.21
IV
Electrical System
I* I 4.15
Engine Oil
IR*R 4.5
II
Engine Oil Filter
R* R
Front Axle
I-A R
VI
Fuel System
I4.8
Fuel Filter
R4.8
Grease Fittings - All
LLL L 6.2
I
Hydraulic Hoses and Tubes
I*** I 4.12
Hydraulic Oil
I-A R** 4.13
III
Hydraulic Oil Filter (2)
R* R**** 4.14
Muffler and Exhaust
I4.16
Radiator Screens
I-C/AR 4.21
Tires
I-A A 4.17
To Next Page
