ADJUSTMENTS 3
GB-15
3.17 SERVICING FRONT DECK___________________________________________________
The front deck can be raised and tilted up to improve
access to the cutting unit and blades for service and
cleaning. Be sure to disengage all drives, engage parking
brake, stop engine and remove ignition key before
working around deck.
To tilt front deck up to its service position:
1. Fully raise front and right wing deck. Stop engine.
2. Remove height of cut pins from front deck and
carefully lift deck to a perpendicular position.
3. Use a chain or heavy rope to tie the front right
caster arm to the right wing deck.
4. Start engine and lower front deck to the ground.
Stop engine and remove ignition key.
To return deck to service:
1. Start engine and fully raise front deck.Stop engine.
Remove rope or chain from right wing deck and
slowly lower front deck.
2. Install height of cut pins in correct set of holes. Start
engine and lower front deck.
3.18 SPECIFIC TORQUE ________________________________________________________
Tie Rod Ball Joints (2): 20 ft lb. (27 Nm).
Steering Cylinder Ball Joints (2): 45 ft lb (61 Nm).
Blade Adapter Bolts (14): 35 - 40 ft lb (47 - 54 Nm).
Center Blade Bolts (7): 75 ft lb (102 Nm).
Rear Wheel Bolts (10): 40 - 50 ft lb (54 - 68 Nm).
Front Lug Nuts (10): 100 - 120 ft lb (135 - 162 Nm)
CAUTION
Removing rope or chain will release the full weight of
the deck. Make sure anyone assisting in this
procedure is made aware of this before removing
rope or chain.
!
