75
> Change from previous revision
Item Part No. Qty. Description Serial Numbers/Notes
1
1001226 1 Muffler
2 1001251 1 Exhaust Pipe
3 553020 1 Gasket, Exhaust Included with Engine
4 555606 4 Bolt and Lockwasher Set Included with Engine
5 1000050 1 Muffler Bracket
6 400188 4 Screw, 5/16-18 x 1” Hex Head
7 452006 12 Flat Washer, 5/16
8 3000098 4 Mount, Isolation
9 444718 4 Locknut, 5/16-18 Center
10 443106 4 Nut, 5/16-18 Hex
11 446136 4 Lockwasher, 5/16 Heavy
12 162236 1 Clamp, 2-1/8” Muffler
24.1 Muffler
Serial No. 69116-5901 and Up
1
2
3
4
5
6
7
8
7
10
11
12
9
7
To Next Page
