59
> Change from previous revision
HR-5111
Item Part No. Qty. Description Serial Numbers/Notes
1
2720206 1 Right Front Lift Arm
2 342033 2 • Bushing
3 2720207 1 Left Front Lift Arm
4 342033 2 • Bushing
5 366037 2 Shaft, Lift Arm Pivot
6 346091 4 Pin, Retaining
7 446136 5 Lockwasher, 5/16 Heavy
8 400184 4 Screw, 5/16-18 x 3/4” Hex Head
9 366045 2 Pin, Lift Cylinder
10 359549 2 Pin, Lift Cylinder
11 460052 4 Cotter Pin, 3/16 x 1-1/2”
12 132871 1 Lift Cylinder
5001091 1 • Seal Kit
13 453023 4 Flat Washer, 1/4
14 471221 4 Grease Fitting, 90°
15 471227 2 Grease Fitting, 45°
16 400276 4 Screw, 3/8-16 x 3” Hex Head
17 453011 5 Flat Washer, 3/8
18 366473 2 Bumper, Lift Arm
19 366610 AR Shim, 0.26” Thick
Add or remove shims as required to
level front deck. See Adjustment
section for details.
19 366611 AR Shim, 0.1975” Thick
19 366612 AR Shim, 0.135 Thick
19 366613 AR Shim, 0.105 Thick
20 366603 1 Spacer, Limit Switch
21 402132 2 Screw, #10-24 x 1-3/4” Slotted
22 446118 2 Lockwasher, #10 Medium
23 446142 5 Lockwasher, 3/8 Heavy
24 443110 5 Nut, 3/8-16 Hex
25 400262 1 Screw, 3/8-16 x 1” Hex Head
26 366438 1 Bracket, Bulkhead
27 362819 1 Washer
28 400188 1 Screw, 5/16-18 x 1” Hex Head
29 366437 1 Bracket, Bulkhead
30 452006 1 Flat Washer, 5/16
31 443106 1 Nut, 5/16-18 Hex
32 3001079 1 Switch, Front Limit
REFERENCE SW10, See 67.1
5000183 1 • Basic Switch
5000184 1 • Operator Head
33 3001078 1 Actuator Arm
34 364694 1 Connector
