Jacobsen HR 5111 Parts And Maintenance Manual

63
> Change from previous revision
HR-5111
Item Part No. Qty. Description Serial Numbers/Notes
1
446136 2 Lockwasher, 5/16 Heavy
2 443106 2 Nut, 5/16-18 Hex
3 453011 12 Flat Washer, 3/8
4 446142 12 Lockwasher, 3/8 Heavy
5 443110 12 Nut, 3/8-16 Hex
6 400272 4 Screw, 3/8-16 x 2-1/4” Hex Head
7 132601 1 Bracket, Deck Roller
8 400264 4 Screw, 3/8-16 x 1-1/4” Hex Head
9 340525 2 Bracket, Deck Roller
10 400280 4 Screw, 3/8-16 x 4” Hex Head
11 3005677 2 Roller, Front Wing Deck
12 404022 2 Screw, 1/4-20 x 1” Truss Head
13 444672 4 Locknut, 3/8-16 Center
14 366989 2 Switch, Deck Limit
REFERENCE SW8 & SW9, See 67.1
15 403766 4 Screw, #4-40 x 3/4” Slotted Brass
16 446102 4 Lockwasher, #4
17 444302 4 Nut, #4-40 Hex
18 3006052 1 Bracket, Right Side Switch
19 3006053 1 Bracket, Left Side Switch
20 132664 2 Hook, Deck Latch
21 400120 4 Screw, 1/4-20 x 2” Hex Head
22 444708 4 Locknut, 1/4-20 Center
23 324887 4 Clip, Deck Latch Cable
24 366566 2 Cable, Deck Latch
25 452008 4 Flat Washer, 3/8
26 453017 2 Flat Washer, 1/2
27 3005678 2 Rear Wing Deck Roller
28 400184 2 Screw, 5/16-18 x 3/4” Hex Head
29 452006 2 Flat Washer, 5/16
30 366929 2 Plate, Clip Mounting
31 400422 2 Screw, 1/2-13 x 4” Hex Head
32 444758 2 Locknut, 1/2-13 Center
33 132523 2 Valve, Back Pressure
555862 1 • Cartridge, Valve
555861 1 • Seal Kit
34 367465 1 Bracket, Valve Mounting
35 453023 2 Flat Washer, 1/4
36 446130 4 Lockwasher, 1/4 Heavy
37 443102 4 Nut, 1/4-20 Hex
38 400274 4 Screw, 3/8-16 x 2-1/2” Hex Head
