77
> Change from previous revision
HR-5111
Item Part No. Qty. Description Serial Numbers/Notes
1
163987 1 Fuel Cap
2 163986 1 Fuel Sender
REFERENCE U8, See 67.1
3N/S1•Gasket
4 403910 5 Screw, #10-24 x 1/2” Truss Head
5 361117 4 Bushing, Fuel
6 366606 2 Washer, Fuel Tank
7 400188 2 Screw, 5/16-18 x 1” Hex Head
8 132647 1 Valve, Drain
9 1001311 1 Valve, Shut Off
10 554752 1 Hose, 3/16” Fuel (Cut to 37”) Tank to Breather Filter
11 554752 1 Hose, 3/16” Fuel (Cut to 12”) Breather Filter to Clamp
12 554752 1 Hose, 3/16” Fuel (Cut to 44”) Engine Return to Tank
13 554748 1 Hose, 5/16” Fuel (Cut to 22”) Tank To Fuel Pump
14 554748 1 Hose, 5/16” Fuel (Cut to 25”) Fuel Pump to Fuel Filter
15 554748 1 Hose, 5/16” Fuel (Cut to 17”) Fuel Filter to Engine
16 361748 2 Valve, Overflow
17 340481 1 Cover, Sender
18 352604 1 Grommet
19 341837 1 Filter, Fuel Breather
20 3005215 1 Fuel Tank
21 366526 10 Clamp, Hose
22 472801 1 Clamp, Hose
23 503626 1 Fuel Filter Included with Engine
557619 1 • Cartridge, Fuel Filter
24 400264 2 Screw, 3/8-16 x 1-1/4” Hex Head
25 443102 2 Nut, 1/4-20 Hex
26 446142 2 Lockwasher, 3/8 Heavy
27 443110 2 Nut, 3/8-16 Hex
28 163574 1 Fuel Pump
REFERENCE U11, See 67.1
29 365976 2 Elbow, 90°
30 400118 2 Screw, 1/4-20 x 1-3/4” Hex Head
31 446130 2 Lockwasher, 1/4 Heavy
To Next Page
