Jacobsen HR 5111

99
> Change from previous revision
HR-5111
Item Part No. Qty. Description Serial Numbers/Notes
1
366607 2 Spacer, Hose
2 359860 2 Clamp, 2 Hose
3 400204 2 Screw, 5/16-18 x 3-1/2”
4 446136 4 Lockwasher, 5/16 Heavy
5 443106 4 Nut, 5/16-18 Hex
6 400114 1 Screw, 1/4-20 x 1-1/4” Hex Head
7 364221 1 Clamp, Double Tube
8 444708 1 Locknut, 1/4-20 Center
9 366345 1 Bracket, Clamp
10 345666 1 Clamp, Hose
11 400112 1 Screw, 1/4-20 x 1” Hex Head
12 400122 1 Screw, 1/4-20 x 2-1/4” Hex Head
13 453023 5 Flat Washer, 1/4
14 446130 4 Lockwasher, 1/4 Heavy
15 443102 4 Nut, 1/4-20 Hex
16 400188 2 Screw, 5/16-18 x 1” Hex Head
17 452006 3 Flat Washer, 5/16
18 365566 3 Clamp
19 400116 2 Screw, 1/4-20 x 1-1/2” Hex Head
20 354080 1 Clamp, Hose
21 550376 1 Bolt Included with Engine
22 550409 1 Washer, Spring Included with Engine
23 550380 1 Washer, Plain Included with Engine
24 361064 1 Clamp
473142 2 Cable Tie
Front Cylinder Return Hose (1)
Deck Valve Hose to Tube (1)
473144 1 Cable Tie, 5/16 x 16” (Not Shown) Steering Hoses to Console Support
473137 4 Cable Tie, 5/16 x 9” (Not Shown)
Front Lift Cylinder Hoses (2)
Front Deck Motor Hoses (1)
Control Valve Hoses (1)
