101
> Change from previous revision
HR-5111
Item Part No. Qty. Description Serial Numbers/Notes
1
132488 1 Tail Light
REFERENCE L11, See 67.1
555869 1 • Tail Light
555870 1 • Grommet
555871 1 • Harness
2 400336 1 Screw, 7/16-14 x 1-1/4” Hex head
3 446148 1 Lockwasher, 7/16 Heavy
4 443114 1 Nut, 7/16-14 Hex
5 3001307 1 Relay SPDT
REFERENCE K5, See 67.1
6 365963 6 Relay, SPST
REFERENCE K2, K3, K6, K7, K8,
K9, See 67.1
7 403908 2 Screw, #10-24 x 3/8” Truss Head
8 3003036 1 Relay, Seat Time Delay
REFERENCE K4, See 67.1
9 5000917 1 Horn
REFERENCE U9, See 67.1
10 5000915 1 • Bracket
11 5000916 1 • Nut
12 403910 2 Screw, #10-24 x 1/2” Truss Head
13 446118 6 Lockwasher, #10 Medium
14 444310 4 Nut, #10-24 Hex
15 400184 1 Screw, 5/16-18 x 3/4” Hex Head
16 403759 4 Screw, 1/4-20 x 5/8” Truss Head
17 366308 1 Plate
18 366373 1 Pad, Seat
19 452006 1 Flat Washer, 5/16
20 446271 1 Lockwasher, 5/16-18 Heavy
21 446130 14 Lockwasher, 1/4 Heavy
22 131905 1 Solenoid, Glow Plug
REFERENCE K1, See 67.1
23 400118 4 Screw, 1/4-20 x 1-3/4” Hex Head
24 453023 4 Flat Washer, 1/4
25 443102 10 Nut, 1/4-20 Hex
26 444312 2 Nut, #10-32 Hex
27 446136 2 Lockwasher, 5/16 Heavy
28 443808 2 Nut, 5/16-24 Hex Jam
29 365962 1 Wire, Solenoid to Glow Plug
30 163918 1 Wire, Circuit Breaker to Solenoid
31 365711 2 Wire, Starter to Circuit Breaker
32 400112 4 Screw, 1/4-20 x 1” Hex head
33 365960 1 Cover, Switch
34 400106 2 Screw, 1/4-20 x 5/8” Hex Head
35 366039 1 Mounting Plate
36 364882 1 Differential Lock Switch
37 360176 1 Wire Cover
To Next Page
