Jacobsen HR 5111

103
> Change from previous revision
HR-5111
Item Part No. Qty. Description Serial Numbers/Notes
1
366618 1 Grommet
2 362263 1 Screw, M10-1.25 x 25 mm
3 365980 1 Screw, M12-1.25 x 20 mm
4 446154 1 Lockwasher, 1/2 Heavy
5 446130 1 Lockwasher, 1/4 Heavy
6 443102 1 Nut, 1/4-20 Hex
7 453023 1 Flat Washer, 1/4
8 361064 1 Clamp
9 400120 1 Screw, 1/4-20 x 2”
10 2720726 1 Negative Battery Cable
11 453011 1 Flat Washer, 3/8
12 446148 1 Lockwasher, 7/16
13 473144 2 Cable Tie
14 473137 4 Cable Tie
15 345671 2 Clamp
16 400190 1 Screw, 5/16-18 x 1-1/4” Hex Head
17 446136 1 Lockwasher, 5/16 Heavy
18 443106 1 Nut, 5/16-18 Hex
19 1002397 1 Positive Battery Cable
20 452006 1 Flat Washer, 5/16
