Jacobsen HR 5111

113
> Change from previous revision
HR-5111
Item Part No. Qty. Description Serial Numbers/Notes
1
131717 8 Yoke, Caster Wheel Spindle
2 453022 20 Flat Washer, 3/4
3 3003207 10 Shaft, Caster Wheel
4 460056 10 Cotter Pin, 3/16 x 2”
5 403578 10 Screw, #10-24 x 1” Hex Head
6 446118 10 Lockwasher, #10
7 444310 10 Nut, #10-24 Hex
1003769 10 Caster Wheel, 11 x 4 x 5
8 550346 1 • Tire, 11 x 4 - 5NHS 4 Ply
9 363233 1 • Valve Stem
10 5002959 1 • Wheel and Bearing
11 5002583 2 • • Bearing, Roller
12 553720 2 • • Bushing, Flanged
13 365772 32 Spacer, Cutting Height
14 62464-4A AR Washer
15 366593 24 Spacer, Caster Wheel
16 3004894 10 Pin, Klick Type
