Jacobsen HR 5111

125
> Change from previous revision
HR-5111
Item Part No. Qty. Description Serial Numbers/Notes
1
557445 2 Relief Valve
2 557444 2 Plug
3 557443 1 Housing
4 557442 1 Rotating Kit
5 557441 1 Valve Plate
6 557440 1 Backplate
7 557439 1 Seal, Cover
8 557438 1 Trunnion Cover
9 557437 1 Cam Plate
10 557436 1 Inner Race
11 557435 1 O-RIng Cover
12 557434 2 Needle Bearing
● 13 N/S 1 Gasket, Housing
14 557433 1 Drive Shaft
15 557426 2 Thrust Race
16 557425 1 Thrust Bearing
● 17 N/S 1 O-RIng
18 557454 2 Dowel Pin
19 557453 2 Screw, Bottom
20 557452 2 Screw, Top
21 557430 1 Washer
22 557451 2 Washer
● 23 N/S 1 Retaining Ring
● 24 N/S 2 Retaining Ring
25 557450 1 Key, Trunnion
● 26 N/S 1 Shaft Seal, Viton
27 557656 1 Shaft Seal, Viton
28 557449 4 Screw
29 557448 2 Spring
30 557447 1 O-RIng
31 338938 1 Coupler
32 557666 1 Tow Valve
● 557446 1 Seal Kit
