Jacobsen HR 5111 Parts And Maintenance Manual

145
> Change from previous revision
HR-5111
Adapter Part
Number.
Dash
Size
Adapter Type (W) O-Ring (X) O-Ring (Y) O-Ring (Z) O-Ring
339979 6-6 Straight Adapter 339909 339897
339983 8-6 Straight Adapter 339910 339897
339984 8-8 Straight Adapter 339910 339898
339989 10-10 Straight Adapter 339911 339899
340003 6-6 Straight Adapter 339906 339897
340029 8-8 45° Adapter 339910 339898
340033 10-10 45° Adapter 339911 339899
340061 6-6 90° Adapter 339909 339897
340065 8-6 90° Adapter 339910 339897
340066 8-8 90° Adapter 339910 339898
340070 10-10 90° Adapter 339911 339899
340074 12-12 90° Adapter 339912 339900
340077 16-16 90° Adapter 339913 339901
340078 6-6 90° Adapter 339909 339897
340089 16-20 90° Adapter 339913 339902
340119 6-6-6 Swivel Run Tee 339909 339909
340120 8-8-8 Swivel Run Tee 339910 339910
340144 8-8-8 Swivel Branch Tee 339910 339910
340215 6-6-6 Bulkhead Run Tee 339909 339909 339909
340263 6-6-6 Straight Thread Run Tee 339909 339897 339909
340269 10-12-12 Straight Thread Run Tee 339911 339899 339912
SAE Boss O-Rings ORS Face Seal O-Rings
Dash Size Thread Size O-Ring Tube Size Thread Size O-Ring
2 5/16-24 459290 4 9/16-18 339908
3 3/8-24 459291 6 11/16-16 339909
4 7/16-20 339896 8 13/16-16 339910
5 1/2-20 459293 10 1-14 339911
6 9/16-18 339897 12 1 3/16-12 339912
8 3/4-16 339898 16 1 7/16-12 339913
10 7/8-14 339899 20 1 11/16-12 339914
12 1 1/16-12 339900 24 2-12 339915
14 1 3/16-12 459296
16 1 5/16-12 339901
20 1 5/8-12 339902
24 1 7/8-12 339903
32 2 1/2-12 339904
