Johnson Controls SABROE UniSAB III User Manual

Engineering manual - UniSAB III 1.10.8
001930 en 2021.06
189/346
Set-up
Set-up/Configuration
No. Function Use
Choices
Drive
1 Motor range Amp
1/2
0 to 2500 Amp
2 Motor range kW
1/2
0 to 2500 kW
3 Motor nom. kW
1/2
0 to 2500 kW or Amp
4 Display
1/2
Amp or kW
5 Motor input signal
1/2 0-1 A/4-20 mA
6
Rotatune * 1/2
No, Yes
7
Drive Com 1/2 AO, LS, DA
8 Motor rpm min.
1/2 500 to 1000 rpm (1) / 0 to 12,000 rpm (2)
9 Motor rpm max.
1/2 1100 to 1800 rpm (1) / 0 to 12,000 rpm (2)
10 Forced speed 2 0 to 12,000 rpm
11 Drive cap limit 2
90 to 100%
12
Motor fan
2 No, Yes
13 Rota recip. 1
Step, Speed
14 Motor rpm min. 2 1 500 to 1000 rpm
Compressor block
1 Compressor type ** 1/2 Screw or reciprocating compressor
2 Swept volume 1/2 0 to 12000 m
3
/h
3 Volume ratio 2 Manual, Auto
4 Fixed Vi ratio 2 1.4, 1.7, 2.2, 2.9, 3.4, 4.0
5
Vi comp. plug valve 2 No, Yes
6 Vi low range 2 No, Yes
7
Vi trigger level 2 NA
8 Vi mode (%) 2 70 to 97%
9 Mechanical zero 2 No, Yes
10 Manual zero 2 0 to 40%
11 Capacity zero 2 0 to 90% [60%]
12 Booster 2 No, Yes
13 Economiser 2 No, Yes
14 Eco low capacity 2 0 to 100%
15 Neutral zone 2 5 to 20%
16 Eco high suction pressure 2 -100 to 100°C/R
17 Unloading 1 Normal, Total, Additional steps, VSD Normal, VSD
Total
18 Unload assist 2 Yes, No
19
Capacity decrease assist rate
2
1 to 5%
20 Volume dead band 2 3 to 70%
21
Oil filter Diff.
1 No, Yes
22
Suction press. grad. 1/2
No, Yes
