Page #188 background image
Engineering manual - UniSAB III 1.10.8
188/346
001930 en 2021.06
Set-up
6.4 Configuration
UniSAB III can be configured to a number of different functions depending on compressor type, refriger-
ant etc. Some settings are factory set but it is always necessary to make some final settings before
start-up.
The immediate configuration can always be checked during operation but if one or more configuration
points should be changed, always stop the compressor and activate the emergency stop while making
the changes.
After changing the configuration, the first press on may initiate the UniSAB III software reset to re-ini-
tialise the database. Within a few seconds after resetting, UniSAB III will show the Favourites/Default
picture. Now release the emergency stop.
The configuration points where a change will initiate a software reset to re-initialise the database to fac-
tory settings are marked with ** in Table 43 and Table 44. The configuration points where a change will
initiate a software restart, but no reset to factory settings, are marked with * in Table 43 and Table 44.
The use of each function is marked with 1) for reciprocating and 2) for screw compressors.
Table 43 and Table 44 include a description of each configuration point as well as possible choices with
reference to the position numbers in the previous pictures.
Set-up/Compressor control
No. Function Use
Choices
1 Mode
1/2 Stop, Manual, Auto, Remote
2
Control on 1/2 Suction pressure, Process out, Discharge pressure,
Hot water, Ext. cool, Ext. heat
3
Capacity controller 1/2
I, PID
4 Auto start
1/2
No, Yes
5
Auto stop
1/2
No, Yes
6
Cold store 1/2
No, Yes
7
Climate compensation 1/2
No, Yes
8 Multisab master
1/2 Start #, Compr. #
Table 43: Set-up/Compressor control
